collisions

English | 日本語

Overview

• This sample first takes broad-phase candidates from space.checkCollisions() using axis-aligned bounding-box overlap checks (AABB), then verifies detailed collisions in the sample itself with sphere-vs-mesh distance checks
• Collision states are color-coded as blue (no collision), green (AABB only), and red (detailed collision), so the difference between broad-phase and detailed checks can be compared at the same time

How to Run

• Open ./collisions.html
• Use a browser with WebGPU support, and check the help panel and HUD together with the sample when needed

webg Features Used

• Space.checkCollisions: detects AABB collision candidate pairs
• Shape.getBoundingBox / mesh access: supports the detailed sphere-vs-mesh checks inside the sample
• Shape.updateMaterial: changes colors according to the current state
• Node: controls moving objects and camera orbits

Checkpoints

• Compare how the hit targets differ between green hits that only passed the AABB candidate test and red hits that also passed the sphere-vs-mesh distance test
• Confirm that the collision-state colors change in sync with the check timing, verifying that the visual-debugging flow is useful
• Change the camera angle and confirm that false positives do not increase, verifying that the collision test itself does not depend on the display

Controls

• ArrowLeft / ArrowRight: orbit the camera horizontally
• ArrowUp / ArrowDown: orbit the camera vertically
• Touch UI (coarse pointer devices): the same operations are available as two button groups, ← / ↑ on the left and ↓ / → on the right
